MICROTEC Fibre Reinforced Tile Adhesives
MICROTEC® Flexible Wall and Floor Tile Adhesive
ARDEX X 77
Fix any tile size or type without slipping and without battens
Spend less time mixing & more time fixing with a 3-hour pot life and 60 minute open time
Get up 40% more coverage than leading competitors
Images
- Information
Information ARDEX X 77
ARDEX X 77 has an open time of up to 60 minutes, which means that you can spread larger areas of adhesive in a single application, enabling you to work more efficiently. Get more from your tile adhesive with 40% more coverage, 3 hour pot life. 1 hour open time and advanced slump resistance.
ARDEX X 77 offers 40% more coverage than leading competitors, that’s up to 8 meters squared from every 20kg bag, or an extra 14 600mm x 300mm tiles fixed!
- Advanced slump resistance – heavier, larger tiles can be fixed
- High yield – up to 6.3m2 coverage @ 3mm thick per bag
- 60 minute open time
- 3 hour pot life
- Ideal for all tile types including porcelain, fully vitrified, mosaics and terrazzo
- Ideal for swimming pools and wet areas
- Suitable for underfloor heating
- For internal and external applications
Click here to view the application video
Unit Size Available: 20kg
Coverage: Approximately 19 litres of mortar, 6.3m2 at 3mm thick
- Technical Data
Technical Data ARDEX X 77
Suitable for External Use or Wet Areas
Yes, including swimming poolsSuitable for Use with Under Tile Heating
YesBed Thickness
1-6mmPot Life
3 hoursOpen Time
60 minutesAdjustment Time
30 minutesGrout After
Walls – 8 hours
Floors – 24 hoursCoverage
Approximately 8m2 per 20kg bag using an 8mm x 8mm notch trowel - Downloads
- Enquiry
Enquiry ARDEX X 77
Consumption Calculator ARDEX X 77
Approximately 19 litres of mortar, 6.3m2 at 3mm thick
